Model No.
型号
|
LF-48
|
LF-55
|
LF-60
|
LF-65
|
|
Suitable Material
适合材料
|
LDPE/HDPE
|
LDPE/HDPE
|
LDPE/HDPE
|
LDPE/HDPE
|
|
Screw Diameter(mm)
螺杆直径
|
48
|
55
|
60
|
65
|
|
Max Screw Speed(r/min)
螺杆转速
|
96
|
80
|
80
|
80
|
|
Traction Shaft Length(mm)
牵引皮轴长度
|
650
|
650
|
800
|
800
|
|
Max Film Width (mm)
膜宽度
|
570+14x2
|
570+14x2
|
770+14x2
|
770+14x2
|
|
Film Thickness(mm)
膜厚度
|
0.01-0.1
|
0.01-0.1
|
0.01-0.1
|
0.01-0.1
|
|
Max Extrusion(kg/hr)
最大挤出量
|
30
|
45
|
55
|
60
|
|
Ratio of Length to Diameter(mm)
螺杆长径比
|
32:1
|
31:1
|
33:1
|
32:1
|
|
Die head diameter
模头直径
|
200
|
200
|
200
|
200
|
|
Extruder Power(kw)
挤出机功率
|
11
|
11
|
15
|
18.5 or 22
|
|
Traction Motor Power(kw)
牵引电机功率
|
2.2
|
2.2
|
2.2
|
2.2
|
|
Heating Device Power(kw)
加热装置功率
|
13.6
|
14.7
|
15.7
|
23.7
|
|
Winder Motor Power（kw）
绕线机电机功率
|
2.2
|
2.2
|
2.2
|
2.2
|
|
CNC Accuracy
数据控制系统精度
|
1000g/+1.5g
|
1000g/+1.5g
|
1000g/+1.5g
|
1000g/+1.5g
|
|
Max winding diameter(mm)
最大缠绕直径
|
1000
|
1000
|
1000
|
1000
|
|
Over Dimension(mm)
外观尺寸
|
6600x2200x5370
|
6600x2700x5370
|
6600x2700x5370
|
6600x2700x5370
|
|
Total Weight(kg)
总重量
|
3050
|
3050
|
3320
|
3320
|
