膜宽(毫米)
Film width (mm)
|
100~320
|
制袋尺寸(毫米)长*宽
Bag size (mm) length * width
|
50*40~200*150
|
卷材直径(毫米)
Roll diameter (mm)
|
≤300
|
包装速度(袋/分钟)
The packing speed (bags / minute)
|
35~100
|
电源总功率(千瓦)
Total power (kw)
|
2.5 kW 220/380 V±10% 50 Hz
|
机器尺寸(厘米)长*宽*高
Machine size (CM) length * width * height
|
65*85*170
|
整机重量(千克)
Machine weight (Kg)
|
≤250
|
适用范围:
Scope of application:
本机适用于膨化食品、虾条、麦片、瓜子、白糖、食盐等松散无粘性粉状、粒状物品自动包装,还适用于药品、茶叶、种子等物料包装。
This machine is suitable for puffed food, shrimp, oatmeal, melon seeds, white sugar, salt and other loose non adhesive powder, granular material automatic packaging, can also be applied to medicine, tea, seeds and other packaging materials.
功能特点:
?Function characteristics:
1、加料、制袋、充填、封口、裁切全自动完成,并带有自动计数;配碳带日期打印(如需充氮,可与充氮机匹配);自动控温,自动光电跟踪,变频无极调速。
2、三边封也可四边封,锯齿形切口
1, feeding, bag making, filling, sealing, cutting is finished automatically, and with automatic counting; with ribbon date printing (for nitrogen, can be matched with the nitrogen charging machine); automatic temperature control, automatic photoelectric tracking, frequency conversion stepless speed regulation.
2, three side seal can be sealed edges, zigzag incision
包装材料:
Packaging.
纸/聚乙烯、玻璃纸/聚乙烯、聚酯/镀铝/聚乙烯、聚酯/聚丙烯、BQPP薄膜、尼龙/聚乙烯、茶叶过滤纸等热封复合材料。
Paper / PE, Pt / PE, PET / Plated Al / PE, PET / PP, BQPP film, nylon / polyethylene, tea filter paper heat sealing composite material.
