用途：Use
|
|
适合于面粉、洗衣粉、精细白糖、奶粉、奶茶粉、果味粉、葡萄糖粉、调料、食品添加剂、农药、保健茶粉、中药粉等粉状物料的自动化包装。
|
|
Suitable for automatic packaging powder materials like all kinds of flour ,washing powder, fine sugar,milk powder,glucose,seasoning,food additive,pesticide,and Chinese medicine.
|
|
|
|
特点：Features
|
1.进口PLC、人机界面控制系统，触摸屏操作简便、直观。
2.伺服送膜系统，定位准确，封切位置均采用自动纠偏装置，自动化程度高。
3.采用智能温控器、温度控制准确，保证封口美观、平整。
4.完善的自动报警保护功能，将损耗减到最低。
5.本机与计量装置配套即可自动完成送料、计量、充填制袋、日期打印的全部包装过程，并自动完成计数。
6.制袋形式：本机可以根据客户需要制成枕式袋、打孔挂袋。
|
Imported PLC control system, simple-operating, visual touch screw.
Servo film feeding system, correct register, sealing and cutting positions adopt automatic correction device, high automation.
Intelligent temperature controller is used, correct temperature control, ensure nice, smooth seal.
Perfect automatic alarming protective function, reduce the consumption up to the lowest.
When the machine is combined with metering equipments, full packaging process including automatic feeding, metering, bag filling, date printing and automatic counting is completed.
Type of bag making: according to customer's demand, the machine can produce
pillow bags, punched hanging bags.
|
|
|
|
主要技术参数 Main Technical parameter
|
|
|
|
包装速度
|
Packing speed
|
15-70bags/min
|
|
制袋尺寸
|
Bag-making size
|
(L)80-350mm(W)80-250mm
|
|
计量范围
|
Filling range
|
150-2000ml
|
|
包装膜宽
|
Film width
|
180-520mm
|
|
包装材料
|
Packing materials
|
OPP/CPP PET/PE 等复合材料
|
|
薄膜厚度
|
Film thickness
|
0.04-0.08mm
|
|
耗气量
|
Air consumption
|
0.36m3/min 0.6MPa
|
|
电源功率
|
Power supply
|
AC220V 50Hz 3.5kw
|
|
机器尺寸
|
Machine dimensions
|
(L)1600×(W)1050×(H)1750mm
|
|
整机重量
|
Machine weight
|
680kg
|
|
|
