用途：Use
|
|
适用于医药、食品、植物种子、化工产品等有一定流动性、松散无粘性粉状、颗粒状物料的自动包装，如：奶粉、面粉、冲剂、小丸、味精、白糖、汤料、麦片、干燥剂等。
|
|
Suitable for automatic packaging liquid, loose non-adhesive powder, particle materials like milk powder, flour, gourmet, sugar, soup, wheat and drying agents.
|
|
|
|
特点：Features
|
1.采用PLC可编程控制器，文本显示屏操作，调整方便，自 动化程度高。
2.先进的光电数控制袋系统、下膜平稳准确，制袋长度能 在操作面直接设定。
3.光标对版，可获得准确的商标图案。
4.该机据不同物料可选配螺杆或量杯计量装置。
|
PLC programmable controller, text display screen operating,
convenient adjustment, high automation.
Advance sensor digital-control bag making system, stable,
correct bottom film run, bag length can be directly set up at operating side.
Plate alignment by cursor, correct brand design can be achieved.
Metering screw stem or glass devices can be optional in this machine according to different materials.
|
|
|
|
主要技术参数 Main Technical parameter
|
|
|
|
包装速度
|
Packing speed
|
30-60bags/min
|
|
制袋尺寸
|
Bag-making size
|
(L)50-120mm (W)40-80mm
|
|
计量范围
|
Filling range
|
(1-20、20-50)ml
|
|
包装膜宽
|
Flim width
|
100-220mm
|
|
制袋形式
|
Shape of bag-making
|
三边封、四边封
three-side sealing,four-sied sealing
|
|
电源功率
|
Power supply
|
AC380V、50Hz 900w
|
|
机器尺寸
|
Machine dimensions
|
(L)800×(W)700×(H)1500mm
|
|
整机重量
|
Machine weight
|
195kg
|
|
|
