铸件名称铸件尺寸
|
L
|
D
|
b
|
套重
|
铸件名称铸件尺寸
|
L
|
D
|
b
|
套重
|
|
Q41-150-1-1/4’
|
140
|
117
|
13
|
|
Q-16-65
|
190
|
180
|
18
|
|
|
Q41-150-1-1/2’
|
165
|
190
|
19
|
|
Q-16-80
|
203
|
195
|
20
|
|
|
Q41-150-2’
|
178
|
152
|
15.9
|
|
Q-16-100
|
305
|
215
|
20
|
|
|
Q41-150-2-1/2’
|
190
|
178
|
17.5
|
|
Q-16-125
|
356
|
245
|
22
|
|
|
Q41-150-3’
|
203
|
190
|
19.1
|
|
Q-16-150
|
394
|
280
|
24
|
|
|
Q41-150-4’
|
229
|
229
|
23.9
|
|
Q-16-200
|
457
|
335
|
26
|
|
|
Q41-150-5’
|
356
|
254
|
23.9
|
|
Q-16-250
|
533
|
405
|
30
|
|
|
Q41-150-6’
|
394
|
279
|
25.4
|
|
Q-25-50
|
216
|
160
|
20
|
|
|
Q41-150-8’
|
457
|
343
|
28.6
|
|
Q-25-65
|
241
|
180
|
22
|
|
|
Q41-150-10’
|
533
|
406
|
30.2
|
|
Q-25-80
|
283
|
195
|
22
|
|
|
Q41-300-1-1/4’
|
178
|
133
|
19
|
|
Q-25-100
|
305
|
230
|
24
|
|
|
Q41-300-1-1/2’
|
190
|
156
|
21
|
|
Q-25-125
|
381
|
270
|
28
|
|
|
Q41-300-2’
|
216
|
165
|
22.3
|
|
Q-25-150
|
403
|
300
|
30
|
|
|
Q41-300-2-1/2’
|
241
|
190
|
25.4
|
|
Q-25-200
|
502
|
360
|
34
|
|
|
Q41-300-3’
|
283
|
210
|
28.6
|
|
Q-25-250
|
568
|
425
|
36
|
|
|
Q41-300-4’
|
305
|
254
|
31.8
|
|
Q-40-25
|
165
|
115
|
16
|
|
|
Q41-300-5’
|
381
|
279
|
35
|
|
Q-40-32
|
180
|
135
|
18
|
|
|
Q41-300-6’
|
403
|
318
|
36.5
|
|
Q-40-40
|
190
|
145
|
18
|
|
|
Q41-300-8’
|
502
|
381
|
41.3
|
|
Q-40-50
|
216
|
160
|
20
|
|
|
Q41-300-10’
|
568
|
444
|
47.7
|
|
Q-40-65
|
241
|
180
|
22
|
|
|
Q-16-15
|
130
|
95
|
14
|
|
Q-40-80
|
283
|
195
|
22
|
|
|
Q-16-20
|
150
|
105
|
14
|
|
Q-40-100
|
305
|
230
|
24
|
|
|
Q-16-25
|
127
|
115
|
14
|
|
Q-40-125
|
381
|
270
|
28
|
|
|
Q-16-32
|
140
|
135
|
16
|
|
Q-40-150
|
403
|
300
|
30
|
|
|
Q-16-40
|
165
|
145
|
16
|
|
Q-40-200
|
502
|
375
|
38
|
|
|
Q-16-50
|
178
|
160
|
16
|
|
|
|
|
|
|
注：L表示结构长度 D表示法兰直径 b表示法兰厚度 国标阀门法兰外园为机械部标准
|
